European Labels
The following pictures of the labels are provided for information purposes and for correct implementation of standards developed by CEN in the framework of the General Product Safety Directive ( EU/ 2001/95). They represent ‘WARNINGS’ assigned on the labels for child care articles are to be used by manufacturers to convey information to consumers. Some of them are owned by the Consumers, Health, Agriculture, and Food Executive Agency (CHAFEA).
Users that wish to implement the related European deliverables, including the labels, are invited to access the national adoptions of the relevant European deliverables through the CEN National Standardization Bodies, a link to which is provided under label description.
TR 13387-5:2018 – clauses 7.2.1 to 7.2.
7.2.1 WARNING - Never leave the child unattended
Figure 1 — Never leave the child unattended
Download the pictogram:
Minimum diameter:
- 25 mm for product marking
- 10 mm for instructions
Proportions: as in Figure 1
Colours:
- outside border: white
- circle and stroke: red
- background inside the circle: white
- child / carer / arrow: black
7.2.2 WARNING - Always use this product with adult supervision
Figure 2 — Always use this product with adult supervision
Download the pictogram:
Minimum diameter:
- 25 mm for product marking
- 10 mm for instructions
Proportions: as in Figure 2
Colours:
- outside border: white
- background inside the circle: blue
- child / carer / arrow: white
7.2.3 WARNING - Always use the restraint system
Figure 3 — Always use the restraint system
Download the pictogram:
Minimum diameter:
- 25 mm for product marking
- 10 mm for instructions
- Proportions: as in Figure 3
Colours:
- outside border: white
- background inside the circle: blue
- child / restraint system / arrows: white
7.2.4 A safety message indicating the range of AGE of a child for which the product is intended
Figure 4 — Range of AGE of a child for which the product is intended
Download the pictogram:
Minimum diameter:
- 25 mm for product marking / purchase information
- 10 mm for instructions
Dimensions of rectangle: proportional to the circle as in Figure 4
Proportions: as in Figure 4
Minimum height of the numbers:
- 4 mm for product marking
- 2 mm for instructions
Colours:
- outside border of the circle: white
- background inside the circle and rectangle: blue
- child / writings / rectangle inner border: white
7.2.5 A safety message indicating the range of WEIGHT of a child for which the product is intended
Figure 5 — Range of WEIGHT of a child for which the product is intended
Download the pictogram:
Minimum diameter:
- 25 mm for product marking / purchase information
- 10 mm for instructions
Dimensions of rectangle: proportional to the circle as in Figure 5
Proportions: as in Figure 5
Minimum height of the numbers:
- 4 mm for product marking
- 2 mm for instructions
Colours:
- outside border of the circle: white
- background inside the circle and rectangle: blue
- child / writings / rectangle inner border: white
7.2.6 A safety message indicating the range of HEIGHT of a child for which the product is intended
Figure 6 — Range of HEIGHT of a child for which the product is intended
Download the pictogram:
Minimum diameter:
- 25 mm for product marking / purchase information
- 10 mm for instructions
Dimensions of rectangle: proportional to the circle as in Figure 6
Proportions: as in Figure 6
Minimum height of the numbers:
- 4 mm for product marking
- 2 mm for instructions
Colours:
- outside border of the circle: white
- background inside the circle and rectangle: blue
- child / arrow / writings / rectangle inner border: white
The symbols presented in the TR 13387-5:2018 are owned by the Consumers, Health, Agriculture and Food Executive Agency (CHAFEA), an executive agency of the European Commission. The symbols can be freely used by anyone but shall not be included as part of any trade mark or design registration.
EN 1888-1:2018 – figure 48
Figure 48 — Maximum WEIGHT of a child for which the product is intended
Download the pictogram:
Minimum diameter:
- 25 mm
Dimensions of rectangle: proportional to the circle as in Figure 48
Proportions: as in Figure 48
Minimum height of the numbers:
- 4 mm
Colours:
- outside border of the circle: white
- background inside the circle and rectangle: blue
- child / writings / rectangle inner border: white
The symbols presented in the EN 1888-1:2018 are owned by the Consumers, Health, Agriculture and Food Executive Agency (CHAFEA), an executive agency of the European Commission. The symbols can be freely used by anyone but shall not be included as part of any trade mark or design registration.
EN 14988/A1:2020 – figure 29
Title: Graphical symbol for “Never leave the child unattended
Download the pictogram:
Minimum diameter of the red circle: 25 mm
Proportions: as in Figure 29
Colours:
- outside border: white
- circle and stroke: red
- background inside the circle: white
- child/carer/arrow: black
The symbols presented in the EN 14988/A1:2020 are owned by the Consumers, Health, Agriculture and Food Executive Agency (CHAFEA), an executive agency of the European Commission. The symbols can be freely used by anyone but shall not be included as part of any trade mark or design registration.
EN 16232+A1:2018 – figures 18 and 19
Title : Graphical symbol for “Never leave the child unattended”
Download the pictogram:
Title: Graphical symbol for “Always use the restraint system”
Download the pictogram:
Minimum diameter: 25 mm
Proportions: as in Figure 18
Colours:
- outside border: white
- circle and stroke: red
- background inside the circle: white
- child / carer / arrow: black
Minimum diameter: 25 mm
Proportions: as in Figure 19
Colours:
- outside border: white
- background inside the circle: blue
- child / restraint system / arrows: white
The symbols presented in the EN 16232+A1:2018 are owned by the Consumers, Health, Agriculture and Food Executive Agency (CHAFEA), an executive agency of the European Commission. The symbols can be freely used by anyone but shall not be included as part of any trade mark or design registration.
EN 17022:2018 – figure 17
Title: Graphical symbol “DANGER – Your child can drown if left alone”
Download the pictogram:
Minimum diameter of each circle:
- 20 mm
Proportions of each circle: as in Figure 16
Colours of the left circle: - outside border: white
- background inside the circle: blue
child / carer / bathing aid / waves: white
Colours of the right circle:
outside border: white
circle and stroke: red
background inside the circle: white
child / carer / bathing aid / waves: black
EN 17072:2018 – figure 19
Title: Graphic Symbol “DANGER – Your child can drown if left alone”
Download the pictogram:
Minimum diameter of each circle:
- 20 mm
Proportions of each circle: as in Figure 19
Colours of the left circle: - outside border: white
- background inside the circle: blue
- child / carer / bathing aid / waves: white
Colours of the right circle: - outside border: white
- circle and stroke: red
- background inside the circle: white
- child / carer / bathing aid / waves: black
